ASTM A36 Steel Angle Bar Manufacturer | Hot Rolled Equal Angle Steel for Structural Applications

ASTM A36 Steel Angle Bar Manufacturer | Hot Rolled Equal Angle Steel for Structural Applications

ASTM A36 Hot Rolled Steel Angle Bar is a high-strength structural steel profile with an L-shaped cross section, manufactured through hot rolling technology. It provides excellent strength, weldability, durability, and dimensional stability.


Availability:



Inquire Add to Basket

Product Description

ZSJH Steel Group supplies high-quality equal and unequal angle steel bars for global construction projects, steel structures, industrial buildings, equipment frames, transmission towers, and fabrication applications.

Our steel angle bars are available in customized sizes, lengths, and surface treatments to meet different engineering requirements.

Steel Angle Bar (2)

Product Features

1. High Structural Strength

Designed for load-bearing applications with excellent mechanical performance.

2. Excellent Weldability

Suitable for welding, cutting, drilling, and fabrication processes.

3. Customized Sizes Available

Various dimensions, thicknesses, and lengths can be supplied according to project requirements.

4. Durable Surface

Available with black finish, galvanized coating, or painted surface for corrosion resistance.

5. Factory Direct Supply

Professional steel fabrication capability with strict quality inspection.

Steel Angle Bar (3)

Item	Specification
Product Name	Steel Angle Bar
Type	Equal Angle / Unequal Angle
Material Grade	ASTM A36 / Q235B / SS400 / S235JR
Manufacturing Process	Hot Rolled
Shape	L-shaped Cross Section
Standard	ASTM A36/A36M, EN10056, JIS G3192
Thickness	3mm - 35mm
Leg Size	20×20mm - 250×250mm
Length	6m / 9m / 12m or Customized
Surface Treatment	Black, Galvanized, Painted
Certification	Mill Test Certificate (MTC)
Packing	Steel Bundle Packing

Element	Content
Carbon (C)	≤0.26%
Manganese (Mn)	≤0.80%
Phosphorus (P)	≤0.04%
Sulfur (S)	≤0.05%

Property	Value
Yield Strength	≥250 MPa
Tensile Strength	400-550 MPa
Elongation	≥20%

Applications

Steel Angle Bar Applications

Steel Structure Buildings

Steel warehouse
Industrial workshop
Prefabricated steel buildings

Structural Support Systems

Bracing systems
Steel frames
Connection members

Industrial Equipment

Machine frames
Equipment supports
Platforms

Infrastructure

Bridges
Transmission towers
Railway structures

Manufacturing Process

Steel Angle Bar

Production Flow

Raw Material Inspection
↓
Steel Billet Heating
↓
Hot Rolling Forming
↓
Straightening
↓
Cutting to Length
↓
Surface Inspection
↓
Quality Testing
↓
Packing & Shipping

Quality Control

ZSJH Steel Group performs strict inspection during production:

✔ Chemical composition testing
✔ Dimension inspection
✔ Mechanical property testing
✔ Surface quality inspection
✔ Ultrasonic testing (optional)
✔ Mill Test Certificate supplied

Packaging

Export Standard Packing

Bundled with steel straps
Waterproof protection
Steel tags marking
Suitable for sea transportation

Why Choose ZSJH Steel Group?

✔ 20+ Years Steel Structure Manufacturing Experience
✔ Factory Direct Steel Supply
✔ Professional Steel Fabrication Capability
✔ Customized Engineering Service
✔ Global Export Experience
✔ Strict Quality Control System

ASTM A36 Steel Angle Bar Equal Angle Steel Hot Rolled Angle Steel Structural Steel Angle Steel Angle Bar Manufacturer Carbon Steel Angle Bar Supplier
