High Strength Structural Steel is designed for structures that require increased load-bearing capacity without excessive material weight. Its higher yield strength allows engineers to reduce plate thickness, member size and overall steel consumption while maintaining structural performance.
Our high-yield steel materials are suitable for long-span buildings, bridges, heavy equipment frames, energy structures and other demanding engineering projects. Plates, sections and fabricated components can be supplied according to project drawings, material specifications and processing requirements.
From raw material preparation to precision cutting, drilling, beveling, bending, welding, surface treatment and export packaging, we provide an integrated supply solution for international structural steel projects.
The material provides greater yield strength than conventional structural steel, making it suitable for heavily loaded members and critical structural connections.
Higher-strength grades can help reduce plate thickness and member dimensions, lowering the dead load of the structure and improving material efficiency.
High-yield steel is widely used for large roof systems, transfer structures, bridge members and other projects where long spans and limited support points are required.
Available grades can be selected according to strength, thickness, welding method and service temperature. Welding procedures can be prepared according to project requirements.
Impact-tested grades are available for structures exposed to cold climates or demanding outdoor environments.
Materials can be supplied as full-size plates, cut parts, drilled components, welded beams or complete prefabricated structural assemblies.
| Item | Available Options |
|---|---|
| Typical Yield Strength | 355–690 MPa |
| Common Grade Range | S355, S420, S460, S500, S690, Q355, Q460, Q550, Q690 |
| Plate Thickness | 6–200 mm or customized |
| Plate Width | 1,500–4,000 mm |
| Plate Length | 6,000–12,000 mm or customized |
| Delivery Condition | Normalized, controlled rolled, TMCP or quenched and tempered |
| Testing Documents | Material Test Certificate available |
| Optional Inspection | Ultrasonic testing, dimensional inspection and third-party inspection |
| Surface Condition | Mill finish, shot blasted, primed or painted |
| Processing Services | Cutting, beveling, drilling, bending, rolling and welding |
| Customization | Production according to drawings and project specifications |
Plates can be cut into beams, connection plates, stiffeners, flanges and other custom shapes using CNC plasma, flame or laser cutting.
Bolt holes, anchor holes and connection openings can be processed according to approved fabrication drawings.
Straight, V-shaped, X-shaped and other welding bevels can be prepared to meet different joint and penetration requirements.
Steel plates can be bent or rolled into curved members, cylinders, transition sections and other engineered shapes.
Built-up beams, box sections and custom assemblies can be fabricated with controlled welding procedures and dimensional inspection.
Available treatments include shot blasting, shop primer, zinc-rich primer and project-specified coating systems.
Our quality control process covers the complete production cycle:
Verification of material grades and certificates
Chemical composition and mechanical property review
Plate thickness and dimensional inspection
Cutting and hole-position inspection
Weld appearance and dimensional checks
Optional ultrasonic or magnetic particle testing
Surface preparation and coating thickness inspection
Final identification and export packaging inspection
Traceable production documentation
Third-party inspection by SGS, BV or TÜV can be arranged when required.
Factory-direct structural steel supply
Material selection support based on project requirements
Customized dimensions and component fabrication
Integrated cutting, drilling, welding and coating services
Strict dimensional and welding quality control
Material certificates and traceable production records
Optional independent third-party inspection
Export packaging suitable for sea transportation
Technical drawing and installation support
Reliable international delivery coordination
It is structural steel with a higher yield strength than standard mild steel. It is selected for projects requiring increased load capacity, reduced member size or lower overall structural weight.
Because the material can carry higher loads, engineers may be able to use thinner plates or smaller structural members. The final reduction must be confirmed through structural calculations.
Grade selection depends on design strength, plate thickness, welding method, service temperature, impact requirements and applicable project standards. Our technical team can review your specifications before quotation.
Yes. We can produce precision-cut plates, built-up beams, box sections, stiffeners, connection plates and welded assemblies according to DWG, DXF, STEP or PDF drawings.
Yes, but the welding consumables, heat input, preheating temperature and welding sequence must match the selected grade and thickness. A suitable welding procedure should be followed.
